ASTERA Sola Bulb
Equipment description
SolaBulb is a 50W PAR-bulb-equivalent, zoomable luminaire with a 15º–50º adjustable beam, refined Fresnel lens, and durable, fan-free operation. A versatile downlight designed to meet the needs of film and events while providing an architectural look.
Technical specification
| Order Codes | AST-BLBSL-E27 AST-BLBSL-E26 AST-BLBSL-B22 |
|---|---|
| LED Engine | Titan LED Engine |
| Colors | RGBMintAmber |
| LED Power Draw | 15 W |
| Luminous Flux 2700 K | 279 Lumens |
| Luminous Flux 3200 K | 353 Lumens |
| Luminous Flux 4000 K | 347 Lumens |
| Luminous Flux 5500 K | 394 Lumens |
| Luminous Flux 6500 K | 376 Lumens |
| Light Output 5500 K 15° @ 1m | 5228 Lux |
| Light Output 5500 K 30° @ 1m | 1652 Lux |
| Light Output 5500 K 50° @ 1m | 615 Lux |
| CRI (Ra) / TLCI 3200 – 6500 K* | ≥96 |
| Beam Angle | 15° – 50° |
| Field Angle | 23° – 73° |
| Strobe | 0 – 25 Hertz |
| DC Input | 9 – 18 VDC – 2.1A |
| DC Connector | 3.5 mm x 1.35 mm |
| AC Input E27 | 100 – 240 VAC, 50/60 Hertz, 0.15 A / 230 VAC |
| AC Input E26 | 100 – 120 VAC, 50/60 Hertz, 0.3 A / 115 VAC |
| AC Input B22 | 100 – 240 VAC, 50/60 Hertz, 0.15 A / 230 VAC |
| AC Connector | E26 / E27 / B22 |
| Power Consumption (max.) | 16.5 W |
| CRMX Receiver | Built-in |
| BluetoothBridge BTB | Built-in |
| Wireless Protocols | CRMX, UHF, Bluetooth, WiFi |
| Wireless Range | CRMX/UHF up to 100 m / 110 yds Bluetooth up to 3 m / 3.3 yds |
| RDM Support | Wireless |
| Infrared Control | Yes |
| IP Rating unwired | IP20: connected via DC socket IP44: connected via AC + FP5-SP in DC socket |
| Ambient Operating Temperature | 0 – 40 °C / 32 – 104 °F |
| Weight | 433 g / 0.955 lbs |
| Dimensions (L x W x D) (zoom in) | 114.6 mm x 91.8 mm x 91.8 mm / 4.51″ x 3.61″ x 3.61″ (E26) 117.6 mm x 91.8 mm x 91.8 mm / 4.63″ x 3.61″ x 3.61″ (E27) 116.2 mm x 91.8 mm x 91.8 mm / 4.57″ x 3.61″ x 3.61″(B22) |
| Dimensions (L x W x D) (zoom out) | 134.6 mm x 91.8 mm x 91.8 mm / 5.3″ x 3.61″ x 3.61″ (E26) 137.6 mm x 91.8 mm x 91.8 mm / 5.42″ x 3.61″ x 3.61″ (E27) 136.2 mm x 91.8 mm x 91.8 mm/ 5.36″ x 3.61″ x 3.61″ (B22) |
| Mounting Options | 3/8″ – 16 UNC thread, 1/4″ – 20 UNC thread, E26/E27/B22 socket |
