RED V-Raptor 8K [X]
Opis sprzętu
Zbudowana w oparciu o te same kluczowe cechy, które posiada oryginalna V-RAPTOR, i wyposażona w zupełnie nowy sensor 8K VV z globalną migawką.
Ponad 17 stopni rozpiętości tonalnej, do 120 klatek na sekundę w 8K — po raz pierwszy w branży połączono duży format, globalną migawkę, wysoką liczbę klatek, wydajność przy słabym oświetleniu i dużą rozpiętość tonalną w jednym narzędziu dla twórców.
Specyfikacja techniczna
| SENSOR SPECS | |
|---|---|
| SENSOR TYPE | V-RAPTOR® [X] 8K VV 35.4MP Global Shutter CMOS |
| EFFECTIVE PIXELS | 8192 x 4320 |
| SENSOR SIZE | 40.96mm x 21.60mm (Diagonal: 46.31mm) |
| DYNAMIC RANGE | 17+ stops |
| LENS MOUNT | |
| MOUNT TYPE | Integrated locking Nikon Z mount or Canon RF mount with electronic communication
Supports /i PL lenses with RED PL Adapters Support for other adapters based on the Nikon Z mount or Canon RF Mount |
| RECORDING | |
| MAX DATA RATES | Up to 800 MB/s using RED branded or other qualified CFexpress media cards1 |
| REDCODE® RAW MAX FRAME RATES |
120 fps at 8K 17:9, 150 fps at 8K 2.4:1
140 fps at 7K 17:9, 175 fps at 7K 2.4:1 160 fps at 6K 17:9, 200 fps at 6K 2.4:1 192 fps at 5K 17:9, 240 fps at 5K 2.4:1 240 fps at 4K 17:9, 300 fps at 4K 2.4:1 320 fps at 3K 17:9, 400 fps at 3K 2.4:1 480 fps at 2K 17:9, 600 fps at 2K 2.4:1 |
| PLAYBACK FRAME RATES (PROJECT TIME BASE) |
23.98, 24, 25, 29.97, 30, 50, 59.94, 60 fps, all resolutions |
| BEST AVAILABLE REDCODE® SETTINGS |
REDCODE HQ, MQ, LQ, and ELQ at 8K 17:9 up to 60 fps
REDCODE LQ and ELQ at 8K 17:9 up to 120 fps REDCODE HQ, MQ, LQ, and ELQ at 6K 17:9 up to 96 fps REDCODE MQ, LQ, and ELQ at 6K 17:9 up to 160 fps REDCODE HQ, MQ, LQ, and ELQ at 4K 17:9 up to 240 fps REDCODE HQ, MQ, LQ, and ELQ at 2K 17:9 up to 480 fps |
| REDCODE® RAW ACQUISITION FORMATS |
8K 17:9, 2:1, 2.4:1, 16:9, 1:1 and Anamorphic 2x, 1.8x, 1.6x, 1.5x, 1.3x, 1.25x
7K 17:9, 2:1, 2.4:1, 16:9, 1:1 and Anamorphic 2x, 1.8x, 1.6x 6K 17:9, 2:1, 2.4:1, 16:9, 1:1 and Anamorphic 1.5x, 1.3x, 1.25x 5K 17:9, 2:1, 2.4:1, 16:9, 1:1 4K 17:9, 2:1, 2.4:1, 16:9, 1:1 3K 17:9, 2:1, 2.4:1, 16:9, 1:1 2K 17:9, 2:1, 2.4:1, 16:9, 1:1 |
| APPLE PRORES | Dedicated recording in ProRes 4444 XQ, ProRes 4444, ProRes 422 HQ, ProRes 422, and ProRes 422 LT at resolutions up to 4K (4096×2160) 120P
Proxy recording available up to ProRes 422 HQ in 2K (2048 x 1080) up to 60P. |
| GENERAL | |
| CONSTRUCTION | Aluminum Alloy |
| DIMENSIONS | 149.63 x 115.5 x 108mm / 5.9 x 4.5 x 4.3 in (LxWxH, largest fixed dims.) |
| WEIGHT | 4.03 lbs (without body cap and CFexpress card) |
| MEDIA TYPE | CFexpress Type B |
| BATTERY TYPE | Integrated V-Lock battery interface optimized for Micro V-Lock Batteries1 |
| DC POWER INPUT | 11-17 V via 6-Pin DC-IN |
| OPERATING TEMPERATURE | 0°C to 40°C (32°F to 104°F) |
| STORAGE TEMPERATURE | -20°C to 50°C (-4°F to 122°F) |
| STORAGE RELATIVE HUMIDITY | 0% to 85% non-condensing |
