Godox AM1600R 8×8
Equipment description
The AM1600R packs a powerful 1600W output and delivers expansive full-color soft light with CCT/HSI/RGBW/GEL/FX color modes. Its GM adjustment offers precise tint control to match any shooting scenario. Paired with an 8*8 seamless soft film, it ensures smooth and diffuse illumination.
The AM1600R offers two formats: 4’x8’ for higher brightness, and 8’x8’ for softer lighting. Both use the same controller. Its modular structure allows light panels to be swapped out easily with Velcro fasteners, while D-rings on the back make it easy to connect or extend panels to suit different shooting needs.
Technical specification
| Model | AM1600R |
| AC INPUT Port | Input: 100-240V～, 50/60Hz, 1800W |
| CCT Range | 1800K – 10000K |
| GM Adjust | -100% ~ 100% |
| Brightness Range | 0.0% ~ 100.0% |
| Dimming Curves | linear, S-curve, exponential, logarithmic |
| FX Modes | 14 |
| CRI | ≈ 96 |
| TLCI | ≈ 95 |
| Light Body/ControllerProtection Grade | IP54 |
| Controlling Methods | DMX 512 controller, support RDM protocol/LumenRadio
CRMX/Etherne/Art-Net&sACN protocol /Bluetooth app/ controller control |
| Bluetooth Controlling Distance | 60m |
| USB-A Port | Firmware Upgrade/5V⎓1.5A Power Supply |
| Working Environment Temperature | -20℃ ~ 45℃ |
| Dimension (without inflatable butterfly frame)≈ | AM48R Light Body: 90.55″*43.31″
AM88R Light Body: 90.55″*90.55″ AM1600R Controller: 10.63″*8.66″*14.57″ |
| Net Weight (without inflatable butterfly frame)≈ | AM48R Light Body: 6.7kg
AM88R Light Body: 12kg AM1600R Controller: 11kg |
