Panasonic EVA1 5.7K
Opis sprzętu
Lekka i kompaktowa. Dostosowana do ujęć z ręki, dokumentu, wydarzeń, teledysków.
Wyposażona w gniazdo EF, podwójne ISO 800 i 2500, sensor 5.7K sprawia, że doskonale sprawdza się w trudnych warunkach oświetleniowych.
Doskonale pasuje jako kamera B lub C do kamer VARICAM35/LT.
Specyfikacja techniczna
| General Specification | – |
| Power | DC 7.28 V (battery operation) DC 12 V (AC adapter operation) |
| Power consumption | 19 W (with LCD/HDMI/SDI ON) |
| Operating temperature | 0 °C to 40 °C (32°F to 104°F) |
| Operating humidity | 10% to 85% (relative humidity) |
| Storage Temperature | -20 °C to 60 °C (-4°F to 140°F) |
| Weight | Body: Approx. 1.2 kg (2.65 lb) (excluding accessories) Shooting: Approx. 2.05 kg (4.52 lb) (with accessories) |
| Dimensions | 135 mm (W) x 133 mm (H) x 170 mm (D) (excluding protrusions and accessories) (5-5/16 inches x 5-1/4 inches x 6-11/16 inches) |
| Camera Unit | – |
| Image Sensor | Super 35 mm, MOS sensor |
| Number of Pixels | Total pixels: Approx. 20.49 megapixels, 6340 (H) x 3232 (V) Effective pixels: Approx. 17.25 megapixels, 5720 (H) x 3016 (V) |
| Sensor Area and Max Frame Rate | S35: 4K/UHD 60 fps/50 fps 2K/HD 120 fps/100 fps 4/3″: 2K/HD 240 fps/200 fps |
| Latitude | 14 stop |
| Log | V-Log |
| Gamma | eV-Look Gamma (2 types) Video Gamma Hybrid Log Gamma (HLG) |
| Gamut | V-Gamut (V-Log) |
| EI Settings | [ISO] mode: NATIVE ISO: 800, 2500 800 Base: 200 to 2000 2500 Base: 1000 to 25600 [dB] mode: (Normal) -12 dB to 8 dB (High) -8 dB to 20 dB |
| Shutter Speed | [deg] mode: 1.0 deg to 358 deg (0.5 deg step) 12 presets [sec] mode: 1/24.1 sec to 1/8000 sec (23.98p) 12 presets |
| Color Temp | ATW, AWB, 2000 K to 15000 K ±10.0 GMg 12 presets |
| Lens Mount | EF mount |
| Image Stabilization | Electric Image Stabilization (EIS) |
| Auto Focus | One push auto focus |
| ND filter | CLEAR, 0.6ND, 1.2ND, 1.8ND, Electrical driven |
| IR Cut Filter | USER assignable IR shooting (filter ON/OFF) |
| Memory Card Recorder | – |
| Recording Media | SDHC memory card (4 GB to 32 GB) SDXC memory card (32 GB to 128 GB) UHS-Ⅰ/UHS-Ⅱ UHS Speed Class3 is supported, Video Speed Class V90 is supported |
| Recording slot | SD memory card slot x 2 |
| Recording Resolution | 4096 x 2160 (4K), 3840 x 2160 (UHD), 2048 x 1080 (2K), 1920 x 1080 (FHD), 1280 x 720 (HD) |
| Recording System Frequency | 59.94p, 50p, 29.97p, 25p, 24p, 23.98p 59.94i, 50i (AVCHD only) |
| 2slot Functions | Simul Rec, Relay Rec, Loop Rec*1, Background Rec*1 |
| Other Rec Functions | Pre Rec, Interval Rec*1, One Shot Rec*1 |
| Digital Video | – |
| Quantizing | MOV: 4:2:2 10 bit/4:2:0 8 bit AVCHD: 4:2:0 8 bit |
| Video Compression Format | H.264/MPEG-4 AVC High Profile |
| Digital Audio | – |
| Recording Audio Format | MOV: 48 kHz/24 bit, 2 CH, Linear PCM AVCHD: 48 kHz/16 bit, 2 CH, Dolby Audio™ |
| Headroom | 18 dB/20 dB (menu switchable) |
| VIDEO OUTPUT | – |
| Video Output | SDI OUT | BNC x 1, SDI REC REMOTE is supported 0.8 V [p-p], 75 Ω, 4K (6G), HD (3G/1.5G) Output format (4:2:2 10 bit): ・4096 x 2160: 29.97p, 25p, 24p, 23.98p ・3840 x 2160: 29.97p, 25p, 24p, 23.98p ・1920 x 1080: 59.94p, 50p, 59.94i, 50i, 29.97p, 29.97PsF, 25p, 25PsF, 24p, 24PsF, 23.98p, 23.98PsF ・1280 x 720p: 59.94p, 50p RAW* output format (10 bit): ・5760 x 3072: 29.97p, 25p, 24p, 23.98p ・4096 x 2160: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p |
| Video Output | HDMI | HDMI x 1, TypeA, HDMI REC REMOTE is supported, Viera Link is NOT supported Output format (4:2:2 10 bit): ・4096 x 2160: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p ・3840 x 2160: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p ・1920 x 1080: 59.94p, 50p, 59.94i, 50i, 29.97p, 25p, 24p, 23.98p ・1280 x 720: 59.94p, 50p ・720 x 480: 59.94p ・720 x 576: 50p Output format (4:2:0 8 bit): ・4096 x 2160: 59.94p, 50p ・3840 x 2160: 59.94p, 50p |
| Audio Input/Output | – |
| Internal Mic | Stereo microphone |
| INPUT1/2 | XLR (3-pin) x 2 (INPUT1/2), input high impedance, LINE/MIC/MIC 48 V (menu switchable) MIC: -40 dBu/-50 dBu/-60 dBu (menu switchable) LINE: 4 dBu/0 dBu (menu switchable) |
| Audio Input/Output | SDI OUT | Linear PCM 2 CH |
| Audio Input/Output | HDMI | Linear PCM 2 CH |
| Phones | 3.5 mm stereo mini jack x 1 |
| Speaker | 20 mm diameter, round x 1 |
| OTHER INPUT/OUTPUT | – |
| TC IN/OUT | BNC x1 for IN/OUT (menu switchable) IN: 1.0 V [p-p] to 4.0 V [p-p], 10 kΩ OUT: 2.0 V [p-p] ±0.5 V [p-p], low impedance |
| LCD | 40-pin (Dedicated) |
| REMOTE | 2.5 mm Super Mini Jack |
| USB 2.0 (HOST) | Type-A, 4-pin for Wireless Module (AJ-WM50) |
| EF Mounting Contact | 8-pin |
| DC IN 12V | DC 12 V (10.5 V to 13.5 V) EIAJ type 4 |
| LCD monitor | – |
| Size | 3.5-type LCD monitor (approx. 1,150,000 dots) Touch panel (MENU control, Shooting assist functions) |
| LCD Monitor | Switches | MIRROR (OFF, B/T, ROTATE) |
| Hand Grip | – |
| Mounting Mechanism | One touch rotatable/Detachable |
| Hand Grip | Switches | REC, MENU/IRIS dial, User switch x 2 |
| Included accessories | – |
| Accessories | Battery (5900 mAh), Battery charger, AC adapter, AC cable, Shoulder strap, Microphone holder, Microphone holder adapter, LCD monitor (with hood and mounting attachment), Handle, Grip, Grip belt, Mount cap |
| Note | *1: Functions to be supported by firmware update. * Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories. * Specifications are subject to change without notice. |
